Product Overview
The Wheel Stand 2.0 is an enhanced, foldable racing stand engineered with precision robotic laser-cut carbon steel and welded construction for exceptional rigidity and performance. Pre-drilled to support major racing wheel brands like Logitech, Thrustmaster, and Fanatec, it also includes shifter/handbrake support and a gaming chair cradle. The stand integrates seamlessly into the NLR ecosystem, being upgradeable to a full cockpit with the GTSeat add-on and compatible with motion platforms.
| Feature | Details |
|---|---|
| Material & Build | Carbon steel (robotic laser-cut & welded); matte black finish |
| Dimensions (L×W×H) | 92.5 cm × 57.5 cm × 78.5 cm (~36.4″ × 22.6″ × 30.9″) |
| Folded Dimensions | 54 cm × 19 cm × 92.5 cm (~21.2″ × 7.5″ × 36.4″) |
| Adjustable Features | Wheel/pedal angle & height, includes shifter/handbrake & chair cradle |
| Compatible Brands | Pre-drilled for Logitech, Thrustmaster, Fanatec |
| Ecosystem Compatibility | GTSeat add-on, motion platforms (With Add-on) |
Features:
- Folds for easy storage
- Gear shifter and handbrake support included to be mounted on left or right side, with height adjustment
- Compatible with Next Level Racing® GTSeat Add-On to be turned into a full cockpit
- Full range of adjustability for wheel and pedal plate
- Next Level Racing® game chair cradle prevents gaming seat from sliding away under heavy braking
- Compatible and predrilled for all major wheels and pedals including Logitech®, Thrustmaster®, Fanatec® and more
Specifications
- Supported Height – 120 – 210 cm or 4ft – 6ft 9 inches
- Supported Max Weight – 150 kg or 330 lbs (Wheel Stand 2.0 combined with GTSeat Add-On)
- Product Dimensions – (L)92.5 X (W)57.5 X (H)78.5 cm, (L) 36.4 X (W) 22.6 X (H) 30.9inches
- Product Weight – 22kg or 48.5lbs
- Color Box Dimensions 23 X 59 X 75cm or 9 x 23.2 x 29.5inches
- Boxed Weight – 25kg or 55.1lbs
- Part Number – NLR-S023
Adjustability
- Foldable frame for easy storage—collapses while preserving mounted electronics
- Fully adjustable wheel and pedal positioning for ergonomic customization
- Swappable shifter/handbrake mounts and integrated gaming chair cradle improve user-specific setups
Frequently Asked Questions (FAQ)
1. What wheel and pedal types is this stand ideal for?
The Wheel Stand 2.0 is ideal for entry to mid-range wheels and pedals from brands like Logitech, Thrustmaster, and Fanatec. It supports both clamped and hard-mounted configurations.
2. Is it adjustable for different setups?
Yes, it offers full adjustability for wheel height and angle, pedal plate angle, and shifter placement. The shifter can be mounted on either side.
3. Can the stand be upgraded to a full cockpit?
Yes, it is compatible with the GTSeat Add-On, allowing users to convert it into a full cockpit with added stability and comfort.
4. Is the stand suitable for small spaces?
Absolutely. It features a foldable design with quick release locking mechanisms, making it easy to store when not in use.
Compatibility:
-
NLR Ecosystem:
- Next Level Racing® GTSeat Add-On
- Next Level Racing® Free Standing Single Monitor Stand
- Next Level Racing® Free Standing Triple Monitor Stand
- Next Level Racing® Motion Platform V3 (Once Wheel Stand 2.0 is combined with the GTSeat Add-On)
- Next Level Racing® Traction Plus Platform (Once Wheel Stand 2.0 is combined with the GTSeat Add-On)
- Next Level Racing® F-GT/GTtrack Combat Flight Pack (Once Wheel Stand 2.0 is combined with the GTSeat Add-On)
- Next Level Racing® Free Standing Keyboard & Mouse Stand
- Next Level Racing® Floor Mat
- Next Level Racing Lockable Castor Wheels
-
Wheelbases:
- MOZA R3
- MOZA R5
- MOZA R9
- Logitech G25
- Logitech G27
- Logitech G29
- Logitech G920
- Logitech G923
- Thrustmaster T500 RS
- Thrustmaster TGT- Remove Pads
- Thrustmaster TGT-II
- Thrustmaster TSPC
- Thrustmaster TX
- Thrustmaster T248
- Thrustmaster T598
- Thrustmaster T818
- Fanatec GT DD PRO
- Fanatec CSL DD
- Camus C5
-
Pedals:
- Fanatec CSL
- Fanatec CSL Elite
- Fanatec Clubsport V3
- Thrustmaster T3PA
- Thrustmaster T300RS
- Thrustmaster TCLM
- Moza R5 Pedals
- Moza Racing CRP
- Moza Racing SR-P
- Logitech G25
- Logitech G27
- Logitech G29
- Logitech G PRO
Troubleshooting
Issue: Stand unstable under intense steering
- Solution: Ensure all bolts are securely tightened. Consider setting up on a firm surface.
Issue: Folding mechanism is stiff or resistant
- Solution: Remove excess load on the plate before folding, and ensure threaded knobs are properly loosened.
Instructions Guide & Video Links
- Instruction Manual (PDF): Download Wheel Stand 2.0 Manual
- Assembly Video: Video Link
Product Comparison
| Feature | Wheel Stand Lite | Wheel Stand 2.0 | Wheel Stand Lite 2.0 |
|---|---|---|---|
| Build Quality | Powder-coated steel | Robotic-cut carbon steel | Powder-coated round steel |
| Stand Additions | None | Chair cradle | Chair cradle |
| Shifter/Handbrake Option | Yes | Yes | Yes |
| Upgrade Path | Limited | Full cockpit via GTSeat Add-on | Full cockpit via Victory Seat Add-on |
| Adjustability | Basic | Extensive (angle, height, fold) | Extensive (angle, height, fold) |
